BD Cathena™ Safety IV Catheter with BD Multiguard™ Technology

Connect to confidence, care and comfort

BD Cathena™ Safety IV Catheters

Ready to learn more? Let’s have a conversation.

Overview
Specifications
Products & Accessories
EIFU & Resources
FAQ

BD Cathena™ Safety IV Catheter with BD Multiguard™ Technology elevates the level of safety by combining needlestick safety with blood control technology compared to a non-safety, non-blood control catheter.

Approximately 90% of hospital patients receive IV therapy.¹ Globally, 1 billion+ peripheral IV catheters are placed every year.²

95% of IV catheters placed are PIVCs.¹ Based on clinical studies, risks associated with PIVC use include:

Potentially high frequency of PIV catheter complications

35–50% of hospitalized patients who receive a PIVC experience a catheter-related complication.³

Occurance of blood exposure

In a study, when clinicians used a PIVC without blood control technology, blood leakage occurred 61% of the time,⁴ risking potential exposure to bloodborne pathogens (BBP).

Multiple PIVC insertion attempts

An emergency department study suggests that first attempt insertion success ranges from 18–79%.⁶

Multiple insertion attempts increase the risk to clinicians of needlestick injury (NSI) and potential exposure to BBP, and undue pain and increased infection risk to the patient.⁶

When clinician safety and patient comfort and care are critical, BD Cathena™ Safety IV Catheter with BD Multiguard™ Technology**:

Eliminates the need for venous compression

during insertion, connections and disconnections, and blood draws, reducing the risk of blood exposure.^**,7
Reduces blood exposure risk**

by stopping blood flow during conections and reconnections.^{^,7}
Provides immediate visual confirmation

of vessel entry with BD Instaflash™ Needle Technology, improving opportunities for first attempt insertion success.^*,8,9
Provides protection from needlestick injuries (NSIs)

with integrated passive safety system.
Offers an ergonomic design

that is easily adaptable to preferred insertion techniqes and provides enhanced control throughout the procedure.
Clinically demonstrated to reduce phlebitis

by up to 69% with BD Vialon™ Catheter Material,compared to an FEP catheter material.^10-12
Supports longer IV dwell times,

with BD Vialon™ Catheter Material.^††,13
Smooth, tapered catheter tip design

with smooth, tapered catheter tip design.^**

BD Cathena™ Safety IV Catheter with BD Multiguard™ Technology

The BD Cathena™ Safety IV Catheter with BD Multiguard™ Technology is designed to enhance the confidence, care and comfort of clinicians and patients.

Disclaimers:

*Compared to a non-notched needle
^tCompared to an FEP catheter
^For up to 10 seconds
**Compared to a non-safety, non-blood control catheter
^ttCompared to PTFE catheter material

1. iData Research Inc. Global Market Report Suite for Vascular Access Devices and Accessories. 2020.

2. Alexandrou E, Ray-Barruel G, Carr PJ, et al. International prevalence of the use of peripheral intravenous catheters. Journal of Hospital Medicine. 2015;10(8):530-533.

3. Helm RE, Klausner JD, Klemperer JD, Flint LM, Huang E. Accepted but unacceptable: peripheral IV catheter failure. J Infus Nurse. 2015;38(3):189-203.

4. Haeseler G, Hildbrand M, Fritscher J. Efficacy and ease of use of an intravenous catheter designed to prevent blood leakage: A prospective observational study. J Vasc Access. 2015;16(3):233-236

5. Rickard C, Webster J, Wallis MC, et al. Routine versus clinically indicated replacement of peripheral intravenous catheters: a randomised controlled equivalence trial. Lancet [serial online]. 2012;380:1066-1074.

6. Carr P, Rippey J, Budgeon C, Cooke M, Higgins N, Rickard C. Insertion of peripheral intravenous cannulae in the Emergency Department: factors associated with first-time insertion success. J Vasc Access. 2016;17(2):182-190.

7. Onia R, Eshu-Wilson I, Arce C, et al. Evaluation of a new safety peripheral IV catheter designed to reduce mucocutaneous blood exposure. CMRO. 2011;27(7):1339-1346.

8. van Loon FHJ, Timmerman R, den Brok GPH, Korsten EHM, Dierick-van Daele ATM, Bouwman ARA. The impact of a notched peripheral intravenous catheter on the first attempt success rate in hospitalized adults: block-randomized trial. JVA. 2021 DOI: 10.1177/1129729821990217.

9. Seetharam AM, Raju U, Suresh K. A randomized controlled study to compare first stick success with Instaflash technology: The FIRSST study. JVA. 2022 DOI:10.1177/11297298221080369.

10. Kus B, Buyukyilmaz F. Effectiveness of Vialon biomaterial versus Teflon catheters for peripheral intravenous placement: A randomized clinical trial. Jpn J Nurs Sci. 2020;e12328. https://doi.org/10.1111/jjns.12328.

11. Maki DG, Ringer M. Risk factors for infusion-related phlebitis with small peripheral venous catheters. Annals of Internal Medicine. 1991;114:845-854.

12. Gaukroger PB, Roberts JG, Manners TA. Infusion thrombophlebitis: a prospective comparison of 645 Vialon and Teflon cannulae in anaesthetic and postoperative use. Anaesthesia and Intensive Care. 1988;16:265-271.

13. Chhugani M, James M, Thokchom S. A randomized controlled trial to assess the effectiveness of Vialon™ cannula versus polytetrafluoroethylene (PTFE) cannula in terms of indwelling time and complications in patients requiring peripheral intravenous cannulation. International Journal of Science and Research (IJSR). 2015;4(12).

14. Richardson D, Kaufman L. Reducing blood exposure risks and costs associated with SPIVC insertion. Nurs Manage. 2011;42(12):31-34.

BD-42420 (06/23)

Without wings product no.	With wings product no.	Size	Inner diameter	Outer diameter	Gravity flow rate	Maximum power injector flow rate for contrast media viscosity ≤11.8 cP(mPa s)	Maximum power injector flow rate for contrast media viscosity ≤27.5 cP(mPa s)
BD Cathena™ Safety IV Catheter with BD Multiguard™ Technology
386860	386880	24 G x 0.75 in 0.7 x 19 mm	0.53 mm	0.71 mm	20 mL/min (1,200 mL/hr)	3.5 mL/sec	2.5 mL/sec
386861	386881	22 G x 1.00 in 0.9 x 25 mm	0.67 mm	0.90 mm	36 mL/min (2,160 mL/hr)	6.0 mL/sec	3.5 mL/sec
—	386882	22 G x 2.00 in 0.9 x 51 mm	0.67 mm	0.90 mm	29 mL/min (1,740 mL/hr)	6.0 mL/sec	3.5 mL/sec
386862	³⁸⁶⁸⁸³	20 G x 1.00 in 1.1 x 25 mm	0.83 mm	1.10 mm	64 mL/min (3,840 mL/hr)	11.0 mL/sec	7.0 mL/sec
386863	386884	20 G x 1.25 in 1.1 x 32 mm	0.83 mm	1.10 mm	60 mL/min (3,600 mL/hr)	11.0 mL/sec	7.0 mL/sec
386864	386885	20 G x 2.00 in 1.1 x 51 mm	0.83 mm	1.10 mm	52 mL/min (3,120 mL/hr)	11.0 mL/sec	7.0 mL/sec
386865	386886	18 G x 1.25 in 1.3 x 32 mm	0.98 mm	1.31 mm	94 mL/min (5,640 mL/hr)	16.0 mL/sec	10.0 mL/sec
386866	386887	18 G x 2.00 in 1.3 x 51 mm	0.98 mm	1.31 mm	87 mL/min (5,200 mL/hr)	16.0 mL/sec	10.0 mL/sec
386867	386888	16 G x 1.25 in 1.7 x 32 mm	1.36 mm	1.74 mm	190 mL/min (11,400 mL/hr)	27.0 mL/sec	18.0 mL/sec
386868	386889	16 G x 2.00 in 1.7 x 51 mm	1.36 mm	1.74 mm	176 mL/min (10,560 mL/hr)	27.0 mL/sec	18.0 mL/sec
BD Cathena™ Safety IV Catheter without BD Multiguard™ Technology
386859	386879	24 G x 0.75 in 0.7 x 19 mm	0.53 mm	0.71 mm	20 mL/min (1,200 mL/hr)	3.5 mL/sec	2.5 mL/sec
386871	386892	22 G x 1.00 in 0.9 x 25 mm	0.67 mm	0.90 mm	37 mL/min (2,220 mL/hr)	6.0 mL/sec	3.5 mL/sec
—	386893	22 G x 2.00 in 0.9 x 51 mm	0.67 mm	0.90 mm	29 mL/min (1,740 mL/hr)	6.0 mL/sec	3.5 mL/sec
386872	386894	20 G x 1.00 in 1.1 x 25 mm	0.83 mm	1.10 mm	65 mL/min (3,900 mL/hr)	11.0 mL/sec	7.0 mL/sec
386873	386895	20 G x 1.25 in 1.1 x 32 mm	0.83 mm	1.10 mm	62 mL/min (3,720 mL/hr)	11.0 mL/sec	7.0 mL/sec
386874	386896	20 G x 2.00 in 1.1 x 51 mm	0.83 mm	1.10 mm	52 mL/min (3,120 mL/hr)	11.0 mL/sec	7.0 mL/sec
386875	386897	18 G x 1.25 in 1.3 x 32 mm	0.98 mm	1.31 mm	104 mL/min (6,240 mL/hr)	16.0 mL/sec	10.0 mL/sec
386876	386898	18 G x 2.00 in 1.3 x 51 mm	0.98 mm	1.31 mm	90 mL/min (5,400 mL/hr)	16.0 mL/sec	10.0 mL/sec
386869	386890	16 G x 1.25 in 1.7 x 32 mm	1.36 mm	1.74 mm	212 mL/min (12,720 mL/hr)	27.0 mL/sec	18.0 mL/sec
386870	386891	16 G x 2.00 in 1.7 x 51 mm	1.36 mm	1.74 mm	200 mL/min (12,000 mL/hr)	27.0 mL/sec	18.0 mL/sec

Sort by:

Our collection of literature on industries and on our offerings gives you information you can use to continue striving for excellence.

Learn more

true

Find our training resources to help improve your clinical practices as part of our goal of advancing the world of health.

Learn More

BD products

true

BD Cathena™ Safety IV Catheter with BD Multiguard™ Technology FAQs

Yes. BD Cathena™ Safety IV Catheter is MR Conditional. Please refer to the Instructions for Use for the specified conditions for use.

Yes. BD Cathena™ Safety IV Catheter are acceptable for use with power injectors up to 325 psi (2,240 kPa).

Yes. BD Cathena™ Safety IV Catheters are available with and without wings.

BD Cathena™ Safety Peripheral IV Catheter (PIVC) with BD Multiguard™ Technology is a multi-use blood control catheter that does not require venous compression during insertion and subsequent luer connection and disconnection.^{^}

BD Cathena™ Safety IV Catheters feature BD Vialon™ Catheter Material. BD Vialon™ is a polyurethane material that has been clinically demonstrated to reduce phlebitis up to 69% compared to an FEP catheter material.^10,11,12,*

BD Cathena™ Safety IV Catheter features BD Instaflash™ Needle Technology designed to provide immediate visual confirmation of vessel entry (flashback) and was clinically demonstrated to improve first-attempt insertion success, reducing painful hit-and-miss insertions.^8,9,*

No. BD Cathena™ Safety IV Catheter has a passive needle shield that automatically covers the needle as it is removed from the catheter, protecting against needlestick injuries and exposure to blood.

Yes. BD Cathena™ Safety IV Catheter can be used to draw blood. BD Cathena™ Catheters are intended to be inserted into a patient’s peripheral vascular system for short-term use to sample blood, monitor blood pressure, or administer fluids.

Yes. The BD Cathena™ Safety IV Catheter is ergonomically designed to be easily adaptable to current insertion techniques, while the anti-rotation tab is designed to enhance tactile control during advancement.
