VAMP™ Closed Blood Sampling Systems
To minimize blood loss during sampling, VAMP™ Closed Blood Sampling systems incorporate an in-line reservoir that allows clinicians to reinfuse rather than discard the clearing volume. Needleless VAMP™ systems are designed to reduce infection, needle sticks, and blood waste associated with conventional blood sampling methods.1-4
VAMP™ Adult System
- VAMP™ Adult System is designed to reduce infection and blood waste associated with traditional blood sampling
- 5 cc reservoir designed for safe and convenient blood sampling in environments where close proximity to the patient is desired
- For use with disposable pressure transducers and for connection to central line catheters and arterial catheters
- Versatile design can be pole mounted on a backplate or used as an arm mount
- Z-site self-sealing sample port reduces blood buildup for collection of undiluted samples and improves infection control compared to traditional sampling methods
VAMP™ Plus System
- Large 12 cc reservoir provides optimized clearing volume
- Choice of one or two Z-site sample sites for flexibility in perioperative settings
- Convenient one-handed operation simplifies sampling and clearing volume reinfusion
- For use with disposable pressure transducer kit or for individual connection to central line or arterial catheters
VAMP™ Jr System
- Designed to meet the volume-critical requirements of pediatric patients
- Smaller 3 cc reservoir optimizes clearing volumes, providing undiluted, accurate blood samples
- Graduated “cc” markings aid in selecting appropriate clearing volume for each patient
- Special contamination hood helps reduce infection risk
- Variety of tubing lengths to accommodate patient size requirements
Model numbers | Description | Unit of Measure |
48VMP106 | 6" sampling kit, sample site, reservoir and two shut-off valves | CS(20) |
| 48VMP120 | 20" sampling kit, sample site and arm-mount reservoir | CS(20) |
| 48VMP160 | 60" sampling kit, sample site and arm-mount reservoir | CS(20) |
| 48VMP184 | 84" sampling kit, sample site and arm-mount reservoir | CS(20) |
| 48VMP284 | 84" sampling kit, sample site and pole-mount reservoir | CS(20) |
| 48AVMP | VAMP™ system anesthesia kit, 68" sampling kit with male / female connector | CS(20) |
Model | Description | Unit of Measure |
VP1 | VAMP™ Plus system reservoir with 60" patient tubing and one sample site located 55" from the patient | CS(10) |
| VP2 | VAMP™ Plus system reservoir with 60" patient tubing and two sample sites located 13" and 55" from the patient | CS(10) |
TruWave™ Disposable Pressure Transducer Arterial Turnarounds
Model | Description | Unit of Measure |
VMP306 | 6" kit with 3 cc reservoir and 2 access sites | CS(20) |
| VMP406 | 6" kit with 3 cc reservoir and 1 sample site | CS(20) |
| VMP426 | 26" kit with 3 cc reservoir and 1 sample site | CS(20) |
Model | Description | Unit of Measure |
VMP400 | VAMP™ system needleless cannula | CS(200) |
- Peruzzi WT, Shapiro BA, Meyer PR, et al. A clinical evaluation of a blood conservation device in medical intensive care unit patients. Crit Care Med. 1993;21(4):501-506.
- Oto J, Yamamoto K, Koike S, et al. Comparison of bacterial contamination of blood conservation system and stopcock system arterial sampling lines used in critically ill patients. Am J Infect Control. 2012;40(6):530-534.
- O’Hare D, Chilvers RJ. Arterial blood sampling practices in intensive care units in England and Wales. Anaesthesia. 2001;56(6):568-571.
- Tang M, Li J, Zhang X, et al. Closed blood conservation device for reducing catheter-related infections in children after cardiac surgery. Crit Care Nurse. 2014;34(5):53-61.
Access our extensive collection of informative product and educational resources, designed to keep you informed and help you achieve excellence.
BD Advanced Patient Monitoring is here to help you stay on top of the latest clinical challenges and make the most of hemodynamic monitoring solutions.
CAUTION: Federal (United States) law restricts this device to sale by or on the order of a physician.
See instructions for use for full prescribing information, including indications, contraindications, warnings, precautions and adverse events.
